PIC-800
Features
- Input Voltage 12V /24V/48V DC optional
- Output Voltage 115V /230V AC optional
- Portable power for AC products, AC outlets for connecting multiple loads
- High surge capacity for products that require more power to start
- High efficiency converts virtually all of the battery’s power to AC
- Mounting brackets for convenient installation
- Heavy duty stud-connection mounting
- Overload and over temperature shut down.
- Low voltage and over voltage alarm.
- Low voltage and over voltage cut off.
Continuous Output Power (Watt): 800
Output Peak Power (Watt): 1600
Input Voltage (DC): 12V/ 24VV / 48V
Output Voltage (AC): 100~120V / 220~240V
Frequency: 50Hz / 60Hz±3Hz
Efficiency: 85~90%
Low Battrey-voltage Alarm (Volt): 10.5V±0.5V/21±1V
Output Peak Power (Watt): 1600
Input Voltage (DC): 12V/ 24VV / 48V
Output Voltage (AC): 100~120V / 220~240V
Frequency: 50Hz / 60Hz±3Hz
Efficiency: 85~90%
Low Battrey-voltage Alarm (Volt): 10.5V±0.5V/21±1V
Low Battrey-voltage shutdown (Volt): 10V±0.5V/20±1V
Output Waveform: Modified sine wave
Over load protection; Yes
Input reverse protection: Yes
Short circuit protection: Yes
Over temperature shutdown: < 65°
Cooling Mode: By Fan
Accessories: Alligator clips (included)
Replaceable Fuse: 30A*3pcs
Net Weight(KGS): 2
QTY(PCS): 4
Carton Meaturement(CM): 53.5*40.5*27.6
Output Waveform: Modified sine wave
Over load protection; Yes
Input reverse protection: Yes
Short circuit protection: Yes
Over temperature shutdown: < 65°
Cooling Mode: By Fan
Accessories: Alligator clips (included)
Replaceable Fuse: 30A*3pcs
Net Weight(KGS): 2
QTY(PCS): 4
Carton Meaturement(CM): 53.5*40.5*27.6
Container 20FT(PCS): 1664
Input Frequency: 50Hz / 60Hz±3Hz
Output Voltage: 100~120V / 220~240V
Output Current: 6A
Battery type:for charging 12v/24v/48v lead acid battery only
Light Switching Current: 1.2A
Efficiency: ≥80%
Overload protection: Yes
Short Circuit protection: Yes
Reverse Polarity Protection: Yes
Dimension(L*W*H)mm: 220*140*75
Input Frequency: 50Hz / 60Hz±3Hz
Output Voltage: 100~120V / 220~240V
Output Current: 6A
Battery type:for charging 12v/24v/48v lead acid battery only
Light Switching Current: 1.2A
Efficiency: ≥80%
Overload protection: Yes
Short Circuit protection: Yes
Reverse Polarity Protection: Yes
Dimension(L*W*H)mm: 220*140*75
