ELECTRIC FORK LIFTER CB-D20

CBD20 Electric Pallet Truck Advantages

  1. AC drive control precision,maintenance-free, safe and reliable.
  2. High-performance hydraulic station, low noise, small vibration, high efficiency.
  3. HMI design of the control handle, easy for left and right hand operation, improve the driving comfort.
  4. Electronic steering systems, lightweight, low noise, more effort.
  5. Emergency reverse device, more safety.
  6. Electromagnetic, regenerative braking system.
Add to Wishlist

Performance

Load capacity: 2000kg
Load centre distance: 600c(mm)
Overall width: 160 B1(mm)
Service weight (with battery): 585 kg
Fork height, lowered: 85 H1(mm)
Max. lift height: 205 h3(mm)
Wheelbase: 1420 y(mm)
Height of tiller: 1450 H6(mm)
Minimum groud clearance: 30H1(mm)

Mechanical

Fork width: 160 e(mm)
Front tread: 365/500 b3(mm)
Aisle width for lengthways, pallets 1000×1200: 2069Ast(mm)
Aisle width for lengthways, pallets 800×1200: 1856Ast(mm)
Container quantity(1*20FT/40FT/40HQ): 12PCS/26PCS/26PCS

Electrical

Fork outside spacing: 550/685 b2(mm)
Fork inside spacing: 230/365 b2(mm)
Battery volts./Cap: 24V/210Ah
Max. lift(unladen/laden): 25/20 mm/s
Max. travel speed(unladen/laden): 6/6 km/h
Turning radius: 1650 Wa(mm)
Max. gradability, laden/unladen: 5%/8%
